Here is a mechanical owl, consisting of a main body printed in one piece without supports and 4 mall parts that are very easy to assemble and do not require supports. It's a mechanical model with multiple gears that are activated by a rod on the lower right side, which in turn moves the owl's wings and eyes. The two rods on the back can be positioned in two different ways, depending on whether you want the owl to lift both wings at once or alternately. To achieve this, you only need to rotate one of the two snap-fit pieces connected to the gear by 180º. To make it work smoothly, simply apply a bit of lubricant to all the gears.
Printing settings
The printing parameters can be found in the attached PDF document (see photo in the description).
The gear tolerances are a minimum of 0.3mm, and there's a bit more tolerance at the base. The maximum overhangs are 16mm. I recommend ensuring good adhesion to the print bed, especially for the small parts in the initial layers.
✔️Print and use the 3D prints of the 3D model for private use, in unlimited quantity; ✔️Share the images of your 3D prints of the 3D model on communication media such as social networks or websites.
What is not allowed:
❌No commercial use or public sharing of the 3D model; ❌No modification or adaptation of the 3D model for public sharing or sale; ❌No distribution, sale, donation or exchange of the digital files of the 3D model.
<p>The printing parameters can be found in the attached PDF document (see photo in the description).</p><p>The gear tolerances are a minimum of 0.3mm, and there's a bit more tolerance at the base. The maximum overhangs are 16mm. I recommend ensuring good adhesion to the print bed, especially for the small parts in the initial layers.</p>
